Features
-
Durable Die-Cast Aluminium Body – Rust-resistant and anti-corrosion design ensures long-lasting use in harsh weather.
-
IP65 Waterproof –
Perfect for both indoor and outdoor use; suitable for hallways, balconies, bathrooms, and exterior walls.
-
High Brightness with Low Consumption – Available in 7W to 50W power options with 85–100lm/W luminous efficacy.
-
Wide Beam Angle – 120° lighting coverage, ideal for large area illumination.
-
CCT Options: 2700K–6000K – Choose warm, neutral, or cool white light to match your space and ambiance.
-
Multiple Size Choices – From Ø145mm to Ø400mm diameter, matching various installation needs.
-
Integrated LED (Epistar / San’an SMD) – Stable performance with CRI 80/90/97 for vivid, natural color rendering.
Details
| Specification | Details |
|---|---|
| Available Wattages | 7W, 15W, 20W, 30W, 40W, 50W |
| Input Voltage | AC 100-240V, 50/60Hz |
| Luminous Efficacy | 85–100 lm/W |
| Beam Angle | 120° |
| CCT (Color Temp) | 2700K–6000K (Warm White to Cool White) |
| CRI | 80 / 90 / 97 |
| Material | Die-cast Aluminum Housing + PC Diffuser |
| IP Rating | IP65 – Waterproof & Dustproof |
| Mount Type | Surface Mount (Ceiling / Wall) |
| Dimensions (mm) | D145×H55 / D220×H75 / D275×H85 / D300×H85 / D350×H85 / D400×H85 |
| LED Chip Brand | Epistar / San’an SMD |
| Working Environment | Indoor & Outdoor Use (Balcony, Corridor, Entrance, Garage, Hallway, etc.) |
| Installation | Surface-mounted with screws (easy and secure) |
| Lifespan | 30,000–50,000 hours |
| Warranty | 2 Years |
| Certifications | CE, RoHS |
Available Models & Sizes
| Model | Power | Size (ØxH) mm | Beam Angle | CCT | CRI |
|---|---|---|---|---|---|
| HB145-B6-F | 7W | Ø145×H55 | 120° | 2700K–6000K | 80/90/97 |
| HB220-B6-F | 15W | Ø220×H55 | 120° | 2700K–6000K | 80/90/97 |
| HB275-B6-F | 20W | Ø275×H55 | 120° | 2700K–6000K | 80/90/97 |
| HB300-B6-F | 30W | Ø300×H55 | 120° | 2700K–6000K | 80/90/97 |
| HB350-B6-F | 40W | Ø350×H85 | 120° | 2700K–6000K | 80/90/97 |
| HB400-B6-F | 50W | Ø400×H85 | 120° | 2700K–6000K | 80/90/97 |
Application Scenarios
Ideal for:
-
Residential hallways & corridors
-
Building entrances & staircases
-
Balcony & patio ceilings
-
Commercial exterior walls
-
Underground parking or basements
Specifications Summary
-
Material: Die-casting aluminum + PC diffuser
-
LED Chip: Epistar / San’an SMD
-
Luminous Efficiency: 85–100 lm/W
-
Input Voltage: AC 220–240V / 50–60Hz
-
Installation: Surface mounted (wall or ceiling)
Key Selling Points (Bullet Table Format)
| Feature | Benefit |
|---|---|
| Die-cast Aluminum Housing | Anti-rust, corrosion-resistant, long-lasting |
| IP65 Waterproof Design | Perfect for outdoor environments: rain, dust, and humidity resistant |
| Wide Range of Wattage Sizes | From 7W to 50W to fit small rooms to large corridors |
| PC Diffuser Cover | Soft, glare-free light distribution |
| Surface Mount Installation | Quick & easy to install on ceilings and walls |
| Customizable Color Temp | Choose from warm, neutral, or daylight white |
